Understanding the Hardware You Have

Product Reverse Engineering in St. George, Utah

Many companies inherit products they don't fully understand (outdated schematics, aging boards, missing design files, etc). We break down the hardware layer by layer, map out how it works, and provide clear paths for repair, redesign, or reproduction. We help companies analyze, document, and rebuild existing hardware and firmware, even when documentation is missing or incomplete. Our reverse engineering work supports legacy products, discontinued components, and systems that need modern replacements.

PCB tracing, recreation, and documentation
Firmware extraction, analysis, and debugging
Obsolete component identification
"Black box" systems analysis
Replicating and modernizing legacy hardware

Our Process

How We Reverse Engineer Products

Reverse engineering requires methodical analysis and precise documentation. We follow a structured process to ensure nothing is missed and every finding is actionable.

01
Disassemble the product, photograph each layer, and catalog every component. PCB traces are mapped, firmware is extracted where possible, and signal paths are documented.
02
Produce schematics, bill of materials, and functional documentation for the existing design. Identify obsolete components and flag areas for improvement.
03
Deliver a clear report with options: repair the existing hardware, redesign with modern components, or reproduce the original. Each path includes scope, timeline, and cost estimates.
